| Description | P | O | Grooves | N | L | D | S | B | Type | d |
| SPA132 | 132 | 137.5 | 1 | 60 | 40 | 20 | 1 | 15 | ||
| 2 | 60 | 45 | 35 | 1 | 15 | |||||
| 3 | 50 | 1 | 15 | |||||||
| 4 | 52 | 97 | 65 | 2 | 15 | |||||
| 5 | 52 | 97 | 80 | 2 | 15 | |||||
| SPA140 | 140 | 145.5 | 1 | 60 | 40 | 107 | 10 | 20 | 3 | 15 |
| 2 | 60 | 45 | 107 | 10 | 35 | 3 | 15 | |||
| 3 4 |
65 | 52 52 |
107 107 |
12 | 50 65 |
3 2 |
15 20 |
|||
| 5 | 52 | 107 | 80 | 2 | 20 | |||||
| SPA150 | 150 | 155.5 | 1 | 60 | 40 | 117 | 10 | 20 | 3 | 15 |
| 2 | 60 | 45 | 117 | 10 | 35 | 3 | 15 | |||
| 3 | 65 | 52 | 117 | 12 | 50 | 3 | 20 | |||
| 4 | 52 | 117 | 65 | 2 | 20 | |||||
| 5 | 52 | 117 | 80 | 2 | 20 | |||||
| SPA160 | 160 | 165.5 | 1 | 60 | 40 | 127 | 10 | 20 | 3 | 15 |
| 2 | 60 | 45 | 127 | 10 | 35 | 3 | 15 | |||
| 3 | 70 | 52 | 127 | 12 | 50 | 3 | 20 | |||
| 4 | 70 | 52 | 127 | 18 | 65 | 4 | 20 | |||
| 5 | 80 | 52 | 127 | 18 | 80 | 4 | 20 | |||
| SPA170 | 170 | 175.5 | 1 | 60 | 40 | 137 | 12 | 20 | 3 | 15 |
| 2 | 60 | 45 | 137 | 12 | 35 | 3 | 15 | |||
| 3 | 70 | 52 | 137 | 12 | 50 | 3 | 20 | |||
| 4 | 80 | 52 | 137 | 18 | 65 | 4 | 20 | |||
| 5 | 80 | 52 | 137 | 18 | 80 | 4 | 20 | |||
| SPA180 | 180 | 185.5 | 1 | 65 | 40 | 147 | 12 | 20 | 3 | 20 |
| 2 | 70 | 50 | 147 | 12 | 35 | 3 | 20 | |||
| 3 | 70 | 52 | 147 | 12 | 50 | 3 | 20 | |||
| 4 5 |
80 80 |
60 65 |
147 147 |
18 18 |
65 80 |
4 4 |
20 20 |
|||
| SPA200 | 200 | 205.5 | 1 2 3 4 5 |
65 70 70 80 80 |
45 50 52 60 65 |
167 167 167 167 167 |
12 12 12 18 1 8 |
20 35 50 65 80 |
3 3 3 4 4 |
20 20 20 20 20 |
| SPA224 | 224 | 229.5 | 1 2 3 4 5 |
65 70 80 90 90 |
45 50 52 60 65 |
192 192 192 192 192 |
12 12 12 18 18 |
20 35 50 65 80 |
3 3 3 4 4 |
20 20 20 20 20 |
| SPA250 | 250 | 255.5 | 1 | 75 | 50 | 217 | 12 | 20 | 3 | 20 |
| 2 | 75 | 50 | 217 | 12 | 35 | 3 | 20 | |||
| 3 | 80 | 60 | 217 | 12 | 50 | 3 | 20 | |||
| 4 | 90 | 65 | 217 | 18 | 65 | 5 | 20 | |||
| 5 | 90 | 65 | 217 | 18 | 80 | 4 | 20 | |||
| SPA280 | 280 | 285.5 | 1 | 75 | 50 | 247 | 14 | 20 | 5 | 20 |
| 2 | 80 | 50 | 247 | 14 | 35 | 5 | 20 | |||
| 3 | 80 | 60 | 247 | 14 | 50 | 5 | 20 | |||
| 4 | 90 | 65 | 247 | 14 | 65 | 5 | 20 | |||
| 5 | 100 | 65 | 247 | 14 | 80 | 6 | 25 |
