Home > All Collections > V-belt pulleys & Coupling > V-Belt Pulleys for Taper Bushes > SPC > SPC-8
  • SPC-8
  • SPC-8
  • SPC-8
  • SPC-8
  • SPC-8
  • SPC-8

SPC-8

No.SPC-8
Material: Steel, Cast iron Product name:SPC cast iron v groove belt pulleys SPC-8 Taper Bush No.:3535,4040,4545,5050 Surface treatment:Black electrophoresis Bore Type:taper bushed bore
GET A QUOTE
  • SPC-8
  • SPC-8
  • SPC-8

Description



Type Grooves P O Type Bush Max Bore E F J K L M N
SPC  200-08 8 200 209.6 3 3535 90 - 213 148 62 89 62 -
SPC  212-08 8 212 221.6 3 3535 90 - 213 160 62 89 62 -
SPC  224-08 8 224 233.6 3 3535 90 - 213 170 62 89 62 -
SPC  236-08 8 236 245.6 3 3535 90 - 213 184 62 89 62 -
SPC  250-08 8 250 259.6 3 3535 90 - 213 198 62 89 62 -
SPC  265-08 8 265 274.6 3 3535 90 - 213 213 62 89 62 -
SPC  280-08 8 280 289.6 6 3535 90 - 213 228 62 89 62 -
SPC  300-08 8 300 309.6 3 4040 100 - 213 247 555 102 555 -
SPC  315-08 8 315 324.6 3 4040 100 - 213 258 555 102 555 -
SPC  335-08 8 335 344.6 6 4040 100 - 213 280 555 102 555 -
SPC  355-08 8 355 364.6 6 4040 100 - 213 304 555 102 555 200
SPC  375-08 8 375 384.6 6 4545 110 - 213 324 495 114 495 200
SPC  400-08 8 400 409.6 6 4545 110 20 213 348 495 114 49.5 220
SPC  425-08 8 425 434.6 6 5050 125 30 213 369 43 127 43 245
SPC  450-08 8 450 459.6 6 5050 125 30 213 394 43 127 43 245
SPC  475-08 8 475 484.6 6 5050 125 30 213 419 43 127 43 245
SPC  500-08 8 500 509.6 5 5050 125 30 213 444 43 127 43 245
SPC  530-08 8 530 539.6 5 5050 125 30 213 474 43 127 43 245
SPC  560-08 8 560 569.6 5 5050 125 - 213 504 43 127 43 245
SPC  630-08 8 630 639.6 5 5050 125 - 213 574 43 127 43 245
SPC  710-08 8 710 719.6 5 5050 125 - 213 656 43 127 43 245
SPC  800-08 8 800 809.6 5 5050 125 - 213 737 43 127 43 245
SPC  1000-08 8 1000 1,009.6 5 5050 125 - 213 937 43 127 43 245
SPC  1250-08 8 1250 1,259.6 5 5050 125 - 213 1187 43 127 43 245
