Catalog
No. |
Module |
L |
Z |
Pitch |
|
|
|
kg/pc |
| p |
S |
A |
Ho |
| |
|
|
mm |
mm |
mm |
mm |
mm |
kg |
| Rack Round-1 x 2000 |
1 x 2000 |
2,010.62 |
640 |
3.14 |
0.5 |
10 |
9.0 |
1.20 |
| Rack Round-1,5 x 2000 |
1,5 x 2000 |
2,016.90 |
428 |
4.71 |
0.6 |
15 |
13.5 |
2.60 |
| Rack Round-2 x 2000 |
2 x 2000 |
2,010.62 |
320 |
6.28 |
0.6 |
20 |
18.0 |
4.52 |
| Rack Round-2,5 x 2000 |
2,5 x 2000 |
2,010.62 |
256 |
7.85 |
0.7 |
25 |
22.5 |
7.20 |
| Rack Round-3 x 2000 |
3 x 2000 |
2,016.90 |
214 |
9.42 |
0.8 |
30 |
27.0 |
10.28 |
| Rack Round-4 x 2000 |
4 x 2000 |
2,010.62 |
160 |
12.57 |
0.8 |
40 |
36.0 |
18.24 |
| Rack Round-5 x 2000 |
5 x 2000 |
2,010.62 |
124 |
15.71 |
1.0 |
50 |
45.0 |
28.40 |
|
